Beginners training

Optics & illumination in machine vision - basics and applications

In machine vision, every detail counts: the choice of the right lens and homogeneous lighting conditions determine how an inspection object is perceived and analysed. Factors such as illumination, appropriate filters, sensor and optics have a significant impact on image quality, ensuring that all the information you want to process is included in the image and therefore the reliability of the inspection results.

Our hands-on training course not only provides you with in-depth knowledge of all the factors that need to be taken into account for stable and reproducible results, but also of the influence of lighting conditions and beam paths with optics and filters on precise inspections.

Training content

LIGHTING BASICS: Important lighting influences, lighting angles, lighting techniques, wavelength of light, light propagation, surface and geometry of the test object, ...
TYPES OF ILLUMINATION & TECHNIQUES: incident light, background, transmitted light, bright field, dark field, dome, coaxial, ...
OPTICS BASICS: Selection criteria for lenses (sensor size, pixel size, object resolution, camera connection...
TECHNICAL OVERVIEW: Focal length, magnification, f-number, depth of field, aperture control, image quality, ...
LENS TYPES: endocentric and telecentric lenses
FILTERS: short pass, long pass, colour filters, blocking filters, polarising filters

We believe in the added value of personal training!

Practical content: Learn from experienced application examples
Technical expertise: Experts teach the basics and provide in-depth knowledge

Next dates	16.07.2025 / 29.10.25 GERMAN
Target audience	Engineers, developers, technicians, quality managers, project managers who work in industrial image processing or automation technology, or who want to learn basic knowledge about optics and lighting in order to design applications precisely and efficiently.
Duration	1 day, approx. 9am - 5pm
Location	82178 Puchheim, Germany
Language	The training can be held in German or English.
Cost	€349 (incl. meals and certificate of attendance)
